Downtown Taps

TECHNICAL SPECIFICATIONS

• Minimum pressure requirements

  0.2 bar

• Maximum pressure requirements

  5 bar

• Inlet fitting connections

  2 x 3/4” BSP male

• Rear inlet supply positions

  Hot/left, cold/right (as viewed from front)

• Handle type

  Dual levers for hot and cold

• Hose connection

  1/2” BSP

• Mounting type

  Deck Mounted with wall mounted handset holder

• Water system

  Suitable for both low and high pressure systems

• Features

  Brass body with zinc handles

  Soft rub shower head nozzles for easy cleaning

  Supplied with a 65mm one function Square Shower handset

  1.25m Chrome plated stainless steel hose

  Diverter which changes water flow from tap to shower handset

  Soft square design

• Colour

  Black and Chrome

• Flow rate (L/min) bath Tap:

  @1 bar - 32.6 lpm
  @2 bar - 46.2 lpm
  @3 bar - 56.4 lpm

• Flow rate (L/min) Shower:

  @1 bar - 13.8 lpm
  @2 bar - 19.9 lpm
  @3 bar - 24.2 lpm

• Guarantee period

  5 years (if the product is registered)
